相关日志如下：

DDR 73dffea49e typ 23/09/20-14:18:32,fwver: v1.14
LPDDR4X, 2112MHz
channel[0] BW=16 Col=10 Bk=8 CS0 Row=16 CS1 Row=16 CS=2 Die BW=16 Size=2048MB
channel[1] BW=16 Col=10 Bk=8 CS0 Row=16 CS1 Row=16 CS=2 Die BW=16 Size=2048MB
channel[2] BW=16 Col=10 Bk=8 CS0 Row=16 CS1 Row=16 CS=2 Die BW=16 Size=2048MB
channel[3] BW=16 Col=10 Bk=8 CS0 Row=16 CS1 Row=16 CS=2 Die BW=16 Size=2048MB
Manufacturer ID:0xff
CH0 RX Vref:27.5%, TX Vref:23.8%,23.8%
CH1 RX Vref:28.8%, TX Vref:22.8%,23.8%
CH2 RX Vref:29.7%, TX Vref:21.8%,21.8%
CH3 RX Vref:30.5%, TX Vref:21.8%,22.8%
change to F1: 528MHz
change to F2: 1068MHz
change to F3: 1560MHz
change to F0: 2112MHz
out
INFO:    Preloader serial: 2
NOTICE:  BL31: v2.3():v2.3-639-g87bcc5dfe:derrick.huang
NOTICE:  BL31: Built : 18:06:16, Sep  9 2023
INFO:    spec: 0x1
INFO:    ext 32k is valid
INFO:    ddr: stride-en 4CH
INFO:    GICv3 without legacy support detected.
INFO:    ARM GICv3 driver initialized in EL3
INFO:    valid_cpu_msk=0xff bcore0_rst = 0x0, bcore1_rst = 0x0
INFO:    l3 cache partition cfg-0
INFO:    system boots from cpu-hwid-0
INFO:    idle_st=0x21fff, pd_st=0x11fff9, repair_st=0xfff70001
INFO:    dfs DDR fsp_params[0].freq_mhz= 2112MHz
INFO:    dfs DDR fsp_params[1].freq_mhz= 528MHz
INFO:    dfs DDR fsp_params[2].freq_mhz= 1068MHz
INFO:    dfs DDR fsp_params[3].freq_mhz= 1560MHz
INFO:    BL31: Initialising Exception Handling Framework
INFO:    BL31: Initializing runtime services
INFO:    BL31: Initializing BL32
I/TC:
I/TC: OP-TEE version: 3.13.0-743-gb5340fd65 #hisping.lin (gcc version 10.2.1 20201103 (GNU Toolchain for the A-profile Architecture 10.2-2020.11 (arm-10.16))) #6 Mon Aug 28 18:01:38 CST 2023 aarch64
I/TC: Primary CPU initializing
I/TC: Primary CPU switching to normal world boot
INFO:    BL31: Preparing for EL3 exit to normal world
INFO:    Entry point address = 0x200000
INFO:    SPSR = 0x3c9

COOLPI LOADER BY YANYI(Nov 15 2023)

DRAM:  8 GiB
Using default environment

switch to partitions #0, OK
mmc0(part 0) is current device
Failed to mount ext2 filesystem...
** Unrecognized filesystem type **
switch to partitions #0, OK
mmc1 is current device
** Invalid partition 1 **
switch to partitions #0, OK
mmc0(part 0) is current device
Failed to mount ext2 filesystem...
** Unrecognized filesystem type **
switch to partitions #0, OK
mmc1 is current device
** Invalid partition 1 **
0 2 1 3 6 8 7 9 edid base block is 0, get edid failed
can't get edid block:0
failed to get edid
hdmi info isn't saved in main block
mode:1920x1080 bus_format:0x100a
hdmi@fde80000:  detailed mode clock 148500 kHz, flags[5]
    H: 1920 2008 2052 2200
    V: 1080 1084 1089 1125
bus_format: 100a
VOP update mode to: 1920x1080p0, type: HDMI0 for VP0
dclk:148500,if_pixclk_div;2,if_dclk_div:4
rockchip_vop2_init: hdmi0_phy_pll may not define
rockchip_vop2_init: hdmi1_phy_pll may not define
assigned-clock-parents's node not define
VP0 set crtc_clock to 148500KHz
VOP VP0 enable Esmart0[356x124->356x124@782x478] fmt[1] addr[0xedf21000]
CEA mode used vic=16
mtmdsclock:148500000
bus_width:0x16a8c8,bit_rate:1485000
hdptx_ropll_cmn_config bus_width:16a8c8 rate:1485000
hdptx phy pll locked!
hdptx phy lane locked!
dw_hdmi_setup HDMI mode
don't use dsc mode
dw hdmi qp use tmds mode
edid base block is 0, get edid failed
can't get edid block:0
failed to get edid
hdmi info isn't saved in main block
mode:1920x1080 bus_format:0x100a
hdmi@fdea0000:  detailed mode clock 148500 kHz, flags[5]
    H: 1920 2008 2052 2200
    V: 1080 1084 1089 1125
bus_format: 100a
VOP update mode to: 1920x1080p0, type: HDMI1 for VP1
dclk:148500,if_pixclk_div;2,if_dclk_div:4
rockchip_vop2_init: hdmi0_phy_pll may not define
rockchip_vop2_init: hdmi1_phy_pll may not define
assigned-clock-parents's node not define
VP1 set crtc_clock to 148500KHz
VOP VP1 enable Esmart1[356x124->356x124@782x478] fmt[1] addr[0xedf21000]
CEA mode used vic=16
mtmdsclock:148500000
bus_width:0x16a8c8,bit_rate:1485000
hdptx_ropll_cmn_config bus_width:16a8c8 rate:1485000
hdptx phy pll locked!
hdptx phy lane locked!
dw_hdmi_setup HDMI mode
don't use dsc mode
dw hdmi qp use tmds mode
boot mode: None
Net Initialization Skipped
Autoboot in 1 seconds
VOP VP0 enable Esmart0[356x124->356x124@782x478] fmt[1] addr[0xedf21000]
VOP VP1 enable Esmart1[356x124->356x124@782x478] fmt[1] addr[0xedf21000]
switch to partitions #0, OK
mmc1 is current device
** Invalid partition 1 **
starting USB...
Bus usb@fc000000: usb maximum-speed not found
trsv ln0 mon rx cdr lock timeout
Register 2000140 NbrPorts 2
Starting the controller
USB XHCI 1.10
Bus usb@fc800000: USB EHCI 1.00
Bus usb@fc840000: USB OHCI 1.0
Bus usb@fc880000: USB EHCI 1.00
Bus usb@fc8c0000: USB OHCI 1.0
Bus usb@fc400000: usb maximum-speed not found
trsv ln0 mon rx cdr lock timeout
Register 2000140 NbrPorts 2
Starting the controller
USB XHCI 1.10
scanning bus usb@fc000000 for devices... 1 USB Device(s) found
scanning bus usb@fc800000 for devices... 1 USB Device(s) found
scanning bus usb@fc840000 for devices... 1 USB Device(s) found
scanning bus usb@fc880000 for devices... 1 USB Device(s) found
scanning bus usb@fc8c0000 for devices... 1 USB Device(s) found
scanning bus usb@fc400000 for devices... 1 USB Device(s) found
       scanning usb for storage devices... 0 Storage Device(s) found

Device 0: unknown device
scanning bus for devices...
SATA link 0 timeout.
AHCI 0001.0300 32 slots 1 ports 6 Gbps 0x1 impl SATA mode
flags: ncq stag pm led clo only pmp fbss pio slum part ccc apst

Device 0: unknown device
switch to partitions #0, OK
mmc0(part 0) is current device
Scanning mmc 0:4...
Found /extlinux/extlinux.conf
Retrieving file: /extlinux/extlinux.conf
203 bytes read in 2 ms (98.6 KiB/s)
1:      rockchip-kernel-5.10
Retrieving file: /extlinux/Image
38471688 bytes read in 220 ms (166.8 MiB/s)
append: earlycon=uart8250,mmio32,0xfe660000 root=PARTUUID=614e0000-0000-4b53-8000-1d28000054a9 rw rootwait rootfstype=ext4 rtleth=ethaddr:5e:c9:b7:16:65:f0
Retrieving file: /extlinux/toybrick.dtb
262130 bytes read in 6 ms (41.7 MiB/s)
## Flattened Device Tree blob at 0x0a100000
   Booting using the fdt blob at 0x0a100000
  'reserved-memory' ramoops@110000: addr=110000 size=f0000
   Loading Device Tree to 00000000eb98d000, end 00000000eb9cfff1 ... OK
switch to partitions #0, OK
mmc0(part 0) is current device
Failed to mount ext2 filesystem...
** Unrecognized filesystem type **
switch to partitions #0, OK
mmc1 is current device
** Invalid partition 1 **
switch to partitions #0, OK
mmc0(part 0) is current device
Failed to mount ext2 filesystem...
** Unrecognized filesystem type **
switch to partitions #0, OK
mmc1 is current device
** Invalid partition 1 **
Adding bank: 0x00200000 - 0x08400000 (size: 0x08200000)
Adding bank: 0x09400000 - 0xf0000000 (size: 0xe6c00000)
Adding bank: 0x100000000 - 0x200000000 (size: 0x100000000)
Adding bank: 0x2f0000000 - 0x300000000 (size: 0x10000000)

Starting kernel ...

[   16.966106][    T0] Booting Linux on physical CPU 0x0000000000 [0x412fd050]
[   16.966124][    T0] Linux version 5.10.160+ (mhos@mhos-HVM-domU) (OHOS (dev) clang version 15.0.4 (llvm-project 81cdec3cd117b1e6e3a9f1ebc4695d790c978463), LLD 15.0.4) #1 SMP PREEMPT Thu Apr 10 17:09:25 CST 2025
[   16.979586][    T0] Machine model: XHiLink RK3588 XH-C200
[   17.026868][    T0] earlycon: uart8250 at MMIO32 0x00000000feb50000 (options '')
[   17.067893][    T0] printk: bootconsole [uart8250] enabled
[   17.081103][    T0] OF: fdt: Reserved memory: failed to reserve memory for node 'drm-cubic-lut@00000000': base 0x0000000000000000, size 0 MiB
[   17.094645][    T0] Reserved memory: created CMA memory pool at 0x00000002ff000000, size 16 MiB
[   17.103916][    T0] OF: reserved mem: initialized node cma, compatible id shared-dma-pool
[   17.225968][    T0] Zone ranges:
[   17.229434][    T0]   DMA32    [mem 0x0000000000200000-0x00000000ffffffff]
[   17.236821][    T0]   Normal   [mem 0x0000000100000000-0x00000002ffffffff]
[   17.244136][    T0] Movable zone start for each node
[   17.249436][    T0] Early memory node ranges
[   17.253992][    T0]   node   0: [mem 0x0000000000200000-0x00000000083fffff]
[   17.261417][    T0]   node   0: [mem 0x0000000009400000-0x00000000efffffff]
[   17.268852][    T0]   node   0: [mem 0x0000000100000000-0x00000001ffffffff]
[   17.276321][    T0]   node   0: [mem 0x00000002f0000000-0x00000002ffffffff]
[   17.283720][    T0] Initmem setup node 0 [mem 0x0000000000200000-0x00000002ffffffff]
[   17.338651][    T0] psci: probing for conduit method from DT.
[   17.344782][    T0] psci: PSCIv1.1 detected in firmware.
[   17.350439][    T0] psci: Using standard PSCI v0.2 function IDs
[   17.356782][    T0] psci: Trusted OS migration not required
[   17.362718][    T0] psci: SMC Calling Convention v1.2
[   17.368468][    T0] percpu: Embedded 31 pages/cpu s88984 r8192 d29800 u126976
[   17.376267][    T0] Detected VIPT I-cache on CPU0
[   17.381318][    T0] CPU features: detected: GIC system register CPU interface
[   17.388960][    T0] CPU features: detected: Virtualization Host Extensions
[   17.396302][    T0] CPU features: detected: ARM errata 1165522, 1319367, or 1530923
[   17.404485][    T0] alternatives: patching kernel code
[   17.412246][    T0] Built 1 zonelists, mobility grouping on.  Total pages: 2059848
[   17.420338][    T0] Kernel command line: earlycon=uart8250,mmio32,0xfeb50000 root=PARTUUID=614e0000-0000 rw rootwait rootfstype=ext4 rtleth=ethaddr:5e:c9:b7:16:65:f0 console=ttyFIQ0 irqchip.gicv3_pseudo_nmi=0 hardware=rk3588 default_boot_device=fe2e0000.mmc ohos.required_mount.system=/dev/block/platform/fe2e0000.mmc/by-name/system@/usr@ext4@ro,barrier=1@wait,required ohos.required_mount.vendor=/dev/block/platform/fe2e0000.mmc/by-name/vendor@/vendor@ext4@ro,barrier=1@wait,required ohos.required_mount.misc=/dev/block/platform/fe2e0000.mmc/by-name/misc@none@none@none@wait,required
[   17.475955][    T0] Dentry cache hash table entries: 1048576 (order: 11, 8388608 bytes, linear)
[   17.485689][    T0] Inode-cache hash table entries: 524288 (order: 10, 4194304 bytes, linear)
[   17.494887][    T0] mem auto-init: stack:all(zero), heap alloc:off, heap free:off
[   17.508948][    T0] software IO TLB: mapped [mem 0x00000000e798d000-0x00000000eb98d000] (64MB)
[   17.588406][    T0] Memory: 8086132K/8370176K available (20222K kernel code, 4162K rwdata, 11724K rodata, 1408K init, 944K bss, 267660K reserved, 16384K cma-reserved)
[   17.604355][    T0] SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=8, Nodes=1
[   17.612279][    T0] rcu: Preemptible hierarchical RCU implementation.
[   17.619135][    T0] rcu:     RCU event tracing is enabled.
[   17.624723][    T0]  Trampoline variant of Tasks RCU enabled.
[   17.630882][    T0]  Tracing variant of Tasks RCU enabled.
[   17.636721][    T0] rcu: RCU calculated value of scheduler-enlistment delay is 30 jiffies.
[   17.651011][    T0] NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
[   17.660132][    T0] GICv3: GIC: Using split EOI/Deactivate mode
[   17.666486][    T0] GICv3: 480 SPIs implemented
[   17.671319][    T0] GICv3: 0 Extended SPIs implemented
[   17.676841][    T0] GICv3: Distributor has no Range Selector support
[   17.683612][    T0] GICv3: 16 PPIs implemented
[   17.688382][    T0] GICv3: CPU0: found redistributor 0 region 0:0x00000000fe680000
[   17.696574][    T0] ITS [mem 0xfe640000-0xfe65ffff]
[   17.701830][    T0] ITS@0x00000000fe640000: allocated 8192 Devices @100120000 (indirect, esz 8, psz 64K, shr 0)
[   17.712610][    T0] ITS@0x00000000fe640000: allocated 32768 Interrupt Collections @100130000 (flat, esz 2, psz 64K, shr 0)
[   17.724450][    T0] ITS: using cache flushing for cmd queue
[   17.730409][    T0] ITS [mem 0xfe660000-0xfe67ffff]
[   17.735597][    T0] ITS@0x00000000fe660000: allocated 8192 Devices @100150000 (indirect, esz 8, psz 64K, shr 0)
[   17.746367][    T0] ITS@0x00000000fe660000: allocated 32768 Interrupt Collections @100160000 (flat, esz 2, psz 64K, shr 0)
[   17.758111][    T0] ITS: using cache flushing for cmd queue
[   17.764222][    T0] GICv3: using LPI property table @0x0000000100170000
[   17.771431][    T0] GIC: using cache flushing for LPI property table
[   17.778175][    T0] GICv3: CPU0: using allocated LPI pending table @0x0000000100180000
[   17.786696][    T0] kfence: initialized - using 524288 bytes for 63 objects at 0x(____ptrval____)-0x(____ptrval____)
[   17.922920][    T0] arch_timer: cp15 timer(s) running at 24.00MHz (phys).
[   17.930091][    T0] clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x588fe9dc0, max_idle_ns: 440795202592 ns
[   17.942183][    T0] sched_clock: 56 bits at 24MHz, resolution 41ns, wraps every 4398046511097ns
[   17.952572][    T0] Calibrating delay loop (skipped), value calculated using timer frequency.. 48.00 BogoMIPS (lpj=80000)
[   17.964112][    T0] pid_max: default: 32768 minimum: 301
[   17.969807][    T0] LSM: Security Framework initializing
[   17.975451][    T0] SELinux:  Initializing.
[   17.979955][    T0] Mount-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[   17.988694][    T0] Mountpoint-cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
[   17.999527][    T1] rcu: Hierarchical SRCU implementation.
[   18.005644][    T1] Platform MSI: msi-controller@fe640000 domain created
[   18.012729][    T1] Platform MSI: msi-controller@fe660000 domain created
[   18.020156][    T1] PCI/MSI: /interrupt-controller@fe600000/msi-controller@fe640000 domain created
[   18.029663][    T1] PCI/MSI: /interrupt-controller@fe600000/msi-controller@fe660000 domain created
[   18.039742][    T1] smp: Bringing up secondary CPUs ...
I/TC: Secondary CPU 1 initializing
I/TC: Secondary CPU 1 switching to normal world boot
I/TC: Secondary CPU 2 initializing
I/TC: Secondary CPU 2 switching to normal world boot
I/TC: Secondary CPU 3 initializing
I/TC: Secondary CPU 3 switching to normal world boot
I/TC: Secondary CPU 4 initializing
I/TC: Secondary CPU 4 switching to normal world boot
I/TC: Secondary CPU 5 initializing
I/TC: Secondary CPU 5 switching to normal world boot
I/TC: Secondary CPU 6 initializing
I/TC: Secondary CPU 6 switching to normal world boot
I/TC: Secondary CPU 7 initializing
I/TC: Secondary CPU 7 switching to normal world boot
[   18.053473][    T0] Detected VIPT I-cache on CPU1
[   18.053495][    T0] GICv3: CPU1: found redistributor 100 region 0:0x00000000fe6a0000
[   18.053509][    T0] GICv3: CPU1: using allocated LPI pending table @0x0000000100190000
[   18.053544][    T0] CPU1: Booted secondary processor 0x0000000100 [0x412fd050]
[   18.061850][    T0] Detected VIPT I-cache on CPU2
[   18.061870][    T0] GICv3: CPU2: found redistributor 200 region 0:0x00000000fe6c0000
[   18.061883][    T0] GICv3: CPU2: using allocated LPI pending table @0x00000001001a0000
[   18.061916][    T0] CPU2: Booted secondary processor 0x0000000200 [0x412fd050]
[   18.070176][    T0] Detected VIPT I-cache on CPU3
[   18.070193][    T0] GICv3: CPU3: found redistributor 300 region 0:0x00000000fe6e0000
[   18.070205][    T0] GICv3: CPU3: using allocated LPI pending table @0x00000001001b0000
[   18.070235][    T0] CPU3: Booted secondary processor 0x0000000300 [0x412fd050]
[   18.078505][    T0] CPU features: detected: Spectre-v4
[   18.078508][    T0] CPU features: detected: Spectre-BHB
[   18.078509][    T0] Detected PIPT I-cache on CPU4
[   18.078520][    T0] GICv3: CPU4: found redistributor 400 region 0:0x00000000fe700000
[   18.078527][    T0] GICv3: CPU4: using allocated LPI pending table @0x00000001001c0000
[   18.078548][    T0] CPU4: Booted secondary processor 0x0000000400 [0x414fd0b0]
[   18.086774][    T0] Detected PIPT I-cache on CPU5
[   18.086786][    T0] GICv3: CPU5: found redistributor 500 region 0:0x00000000fe720000
[   18.086794][    T0] GICv3: CPU5: using allocated LPI pending table @0x00000001001d0000
[   18.086815][    T0] CPU5: Booted secondary processor 0x0000000500 [0x414fd0b0]
[   18.095054][    T0] Detected PIPT I-cache on CPU6
[   18.095065][    T0] GICv3: CPU6: found redistributor 600 region 0:0x00000000fe740000
[   18.095072][    T0] GICv3: CPU6: using allocated LPI pending table @0x00000001001e0000
[   18.095093][    T0] CPU6: Booted secondary processor 0x0000000600 [0x414fd0b0]
[   18.103324][    T0] Detected PIPT I-cache on CPU7
[   18.103335][    T0] GICv3: CPU7: found redistributor 700 region 0:0x00000000fe760000
[   18.103343][    T0] GICv3: CPU7: using allocated LPI pending table @0x00000001001f0000
[   18.103364][    T0] CPU7: Booted secondary processor 0x0000000700 [0x414fd0b0]
[   18.103419][    T1] smp: Brought up 1 node, 8 CPUs
[   18.323636][    T1] SMP: Total of 8 processors activated.
[   18.329327][    T1] CPU features: detected: Privileged Access Never
[   18.335977][    T1] CPU features: detected: LSE atomic instructions
[   18.342636][    T1] CPU features: detected: User Access Override
[   18.349037][    T1] CPU features: detected: 32-bit EL0 Support
[   18.355168][    T1] CPU features: detected: Common not Private translations
[   18.362529][    T1] CPU features: detected: RAS Extension Support
[   18.369031][    T1] CPU features: detected: Data cache clean to the PoU not required for I/D coherence
[   18.378905][    T1] CPU features: detected: CRC32 instructions
[   18.385061][    T1] CPU features: detected: Speculative Store Bypassing Safe (SSBS)
[   18.393141][    T1] CPU features: detected: RCpc load-acquire (LDAPR)
[   18.436869][    T1] CPU: All CPU(s) started at EL2
[   18.444198][    T1] devtmpfs: initialized
[   18.459154][    T1] Registered cp15_barrier emulation handler
[   18.465306][    T1] Registered setend emulation handler
[   18.470911][    T1] KASLR disabled due to lack of seed
[   18.476445][    T1] clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 6370867519511994 ns
[   18.487643][    T1] futex hash table entries: 2048 (order: 5, 131072 bytes, linear)
[   18.496058][    T1] pinctrl core: initialized pinctrl subsystem
[   18.502697][   T54] bbox:[info][blackbox_core.c:262] wait for log part [/data] begin!
[   18.511063][    T1] NET: Registered protocol family 16
[   18.517544][    T1] DMA: preallocated 1024 KiB GFP_KERNEL pool for atomic allocations
[   18.526000][    T1] DMA: preallocated 1024 KiB GFP_KERNEL|GFP_DMA32 pool for atomic allocations
[   18.535356][    T1] audit: initializing netlink subsys (disabled)
[   18.541946][   T62] audit: type=2000 audit(0.373:1): state=initialized audit_enabled=0 res=1
[   18.542283][    T1] Registered FIQ tty driver
[   18.555648][    T1] thermal_sys: Registered thermal governor 'fair_share'
[   18.555649][    T1] thermal_sys: Registered thermal governor 'step_wise'
[   18.562943][    T1] thermal_sys: Registered thermal governor 'user_space'
[   18.570097][    T1] thermal_sys: Registered thermal governor 'power_allocator'
[   18.577426][    T1] thermal thermal_zone1: power_allocator: sustainable_power will be estimated
[   18.594487][    T1] thermal thermal_zone2: power_allocator: sustainable_power will be estimated
[   18.603794][    T1] thermal thermal_zone3: power_allocator: sustainable_power will be estimated
[   18.613126][    T1] thermal thermal_zone4: power_allocator: sustainable_power will be estimated
[   18.622382][    T1] thermal thermal_zone5: power_allocator: sustainable_power will be estimated
[   18.631644][    T1] thermal thermal_zone6: power_allocator: sustainable_power will be estimated
[   18.640974][    T1] cpuidle: using governor menu
[   18.646028][    T1] hw-breakpoint: found 6 breakpoint and 4 watchpoint registers.
[   18.654174][    T1] ASID allocator initialised with 65536 entries
[   18.661924][    T1] ramoops: dmesg-0 0x28000@0x0000000000110000
[   18.668286][    T1] ramoops: console 0x80000@0x0000000000138000
[   18.674640][    T1] ramoops: pmsg    0x40000@0x00000000001b8000
[   18.681000][    T1] printk: console [ramoops-1] enabled
[   18.686679][    T1] pstore: Registered ramoops as persistent store backend
[   18.694071][    T1] ramoops: using 0xf0000@0x110000, ecc: 0
[   18.737859][    T1] rockchip-gpio fd8a0000.gpio: probed /pinctrl/gpio@fd8a0000
[   18.745798][    T1] rockchip-gpio fec20000.gpio: probed /pinctrl/gpio@fec20000
[   18.753709][    T1] rockchip-gpio fec30000.gpio: probed /pinctrl/gpio@fec30000
[   18.761595][    T1] rockchip-gpio fec40000.gpio: probed /pinctrl/gpio@fec40000
[   18.769478][    T1] rockchip-gpio fec50000.gpio: probed /pinctrl/gpio@fec50000
[   18.777225][    T1] rockchip-pinctrl pinctrl: probed pinctrl
[   18.793954][    T1] vcc5v0_sys: supplied by vcc12v_dcin
[   18.799592][    T1] vcc5v0_usbdcin: supplied by vcc12v_dcin
[   18.805639][    T1] vcc5v0_usb: supplied by vcc5v0_usbdcin
[   18.811618][    T1] vcc3v3_pcie30: supplied by vcc12v_dcin
[   18.817627][    T1] vbus5v0_typec: supplied by vcc5v0_usb
[   18.823441][    T1] vcc3v3_au5426: supplied by vcc5v0_sys
[   18.835985][    T1] vcc5v0_host: supplied by vcc5v0_usb
[   18.841669][    T1] usbhub_rst: supplied by vcc5v0_usb
[   18.847272][    T1] usbhub1_rst: supplied by vcc5v0_usb
[   18.852911][    T1] vcc_1v1_nldo_s3: supplied by vcc5v0_sys
[   18.859117][    T1] iommu: Default domain type: Translated
[   18.867995][    T1] SCSI subsystem initialized
[   18.872810][    T1] usbcore: registered new interface driver usbfs
[   18.879438][    T1] usbcore: registered new interface driver hub
[   18.885830][    T1] usbcore: registered new device driver usb
[   18.891978][    T1] mc: Linux media interface: v0.10
[   18.897340][    T1] videodev: Linux video capture interface: v2.00
[   18.903997][    T1] pps_core: LinuxPPS API ver. 1 registered
[   18.910061][    T1] pps_core: Software ver. 5.3.6 - Copyright 2005-2007 Rodolfo Giometti <giometti@linux.it>
[   18.920581][    T1] PTP clock support registered
[   18.925717][    T1] arm-scmi firmware:scmi: SCMI Notifications - Core Enabled.
[   18.933479][    T1] arm-scmi firmware:scmi: SCMI Protocol v2.0 'rockchip:' Firmware version 0x0
[   18.943564][    T1] Advanced Linux Sound Architecture Driver Initialized.
[   18.950967][    T1] Bluetooth: Core ver 2.22
[   18.955549][    T1] NET: Registered protocol family 31
[   18.961042][    T1] Bluetooth: HCI device and connection manager initialized
[   18.968580][    T1] Bluetooth: HCI socket layer initialized
[   18.974462][    T1] Bluetooth: L2CAP socket layer initialized
[   18.980623][    T1] Bluetooth: SCO socket layer initialized
[   18.987810][    T1] rockchip-cpuinfo cpuinfo: SoC            : 35881000
[   18.994024][    T1] rockchip-cpuinfo cpuinfo: Serial         : e84035bfbbb6e7e2
[   19.001449][    T1] clocksource: Switched to clocksource arch_sys_counter
[   19.263465][    T1] VFS: Disk quotas dquot_6.6.0
[   19.268445][    T1] VFS: Dquot-cache hash table entries: 512 (order 0, 4096 bytes)
[   19.277258][    T1] NET: Registered protocol family 2
[   19.282822][    T1] IP idents hash table entries: 131072 (order: 8, 1048576 bytes, linear)
[   19.293507][    T1] tcp_listen_portaddr_hash hash table entries: 4096 (order: 4, 65536 bytes, linear)
[   19.303426][    T1] TCP established hash table entries: 65536 (order: 7, 524288 bytes, linear)
[   19.313003][    T1] TCP bind hash table entries: 65536 (order: 8, 1048576 bytes, linear)
[   19.322299][    T1] TCP: Hash tables configured (established 65536 bind 65536)
[   19.330104][    T1] UDP hash table entries: 4096 (order: 5, 131072 bytes, linear)
[   19.338198][    T1] UDP-Lite hash table entries: 4096 (order: 5, 131072 bytes, linear)
[   19.346829][    T1] NET: Registered protocol family 1
[   19.352594][    T1] RPC: Registered named UNIX socket transport module.
[   19.359617][    T1] RPC: Registered udp transport module.
[   19.365431][    T1] RPC: Registered tcp transport module.
[   19.371235][    T1] RPC: Registered tcp NFSv4.1 backchannel transport module.
[   19.379164][    T1] PCI: CLS 0 bytes, default 64
[   19.384667][    T1] rockchip-thermal fec00000.tsadc: Missing rockchip,grf property
[   19.393141][    T1] rockchip-thermal fec00000.tsadc: tsadc is probed successfully!
[   19.401737][    T1] hw perfevents: enabled with armv8_pmuv3 PMU driver, 7 counters available
[   19.413149][    T1] Initialise system trusted keyrings
[   19.418700][    T1] workingset: timestamp_bits=46 max_order=21 bucket_order=0
[   19.427770][    T1]  hmdfs: hmdfs_init_configfs() init configfs
[   19.434159][    T1] Registering sharefs
[   19.434189][    T1]  sharefs: sharefs_init_configfs() init configfs
[   19.445365][    T1] NFS: Registering the id_resolver key type
[   19.451518][    T1] Key type id_resolver registered
[   19.456716][    T1] Key type id_legacy registered
[   19.461734][    T1] ntfs: driver 2.1.32 [Flags: R/O].
[   19.467139][    T1] fuse: init (API version 7.32)
[   19.472258][    T1] SGI XFS with security attributes, no debug enabled
[   19.499162][    T1] Key type asymmetric registered
[   19.504284][    T1] Asymmetric key parser 'x509' registered
[   19.510271][    T1] Block layer SCSI generic (bsg) driver version 0.4 loaded (major 241)
[   19.518892][    T1] io scheduler mq-deadline registered
[   19.524490][    T1] io scheduler kyber registered
[   19.529573][    T1] io scheduler bfq registered
[   19.542023][  T152] rk-pcie fe170000.pcie: invalid prsnt-gpios property in node
[   19.542098][    T1] pwm-backlight backlight: supply power not found, using dummy regulator
[   19.555160][  T152] rk-pcie fe170000.pcie: IRQ msi not found
[   19.558859][    T1] pwm-backlight backlight_1: supply power not found, using dummy regulator
[   19.564756][  T152] rk-pcie fe170000.pcie: use outband MSI support
[   19.564759][  T152] rk-pcie fe170000.pcie: Missing *config* reg space
[   19.573794][    T1] of_pwm_get(): can't parse "pwms" property
[   19.580406][  T152] rk-pcie fe170000.pcie: host bridge /pcie@fe170000 ranges:
[   19.587248][    T1] pwm-backlight backlight_1: unable to request PWM
[   19.593445][  T152] rk-pcie fe170000.pcie:      err 0x00f2000000..0x00f20fffff -> 0x00f2000000
[   19.601101][    T1] pwm-backlight: probe of backlight_1 failed with error -2
[   19.607856][  T152] rk-pcie fe170000.pcie:       IO 0x00f2100000..0x00f21fffff -> 0x00f2100000
[   19.607861][  T152] rk-pcie fe170000.pcie:      MEM 0x00f2200000..0x00f2ffffff -> 0x00f2200000
[   19.617166][    T1] iep: Module initialized.
[   19.624549][  T152] rk-pcie fe170000.pcie:      MEM 0x0980000000..0x09bfffffff -> 0x0980000000
[   19.624569][  T152] rk-pcie fe170000.pcie: Missing *config* reg space
[   19.633738][    T1] mpp_service mpp-srv: unknown mpp version for missing VCS info
[   19.642954][  T152] rk-pcie fe170000.pcie: invalid resource
[   19.647516][    T1] mpp_service mpp-srv: probe start
[   19.684166][    T1] mpp_vdpu2 fdb50400.vdpu: Adding to iommu group 1
[   19.691147][    T1] mpp_vdpu2 fdb50400.vdpu: probe device
[   19.696992][    T1] mpp_vdpu2 fdb50400.vdpu: reset_group->rw_sem_on=0
[   19.703901][    T1] mpp_vdpu2 fdb50400.vdpu: reset_group->rw_sem_on=0
[   19.710922][    T1] mpp_vdpu2 fdb50400.vdpu: probing finish
[   19.717009][    T1] mpp_vepu2 jpege-ccu: probing start
[   19.722537][    T1] mpp_vepu2 jpege-ccu: probing finish
[   19.728180][    T1] mpp_vepu2 fdb50000.vepu: Adding to iommu group 1
[   19.734988][    T1] mpp_vepu2 fdb50000.vepu: probing start
[   19.740924][    T1] mpp_vepu2 fdb50000.vepu: reset_group->rw_sem_on=0
[   19.747814][    T1] mpp_vepu2 fdb50000.vepu: reset_group->rw_sem_on=0
[   19.754771][    T1] mpp_vepu2 fdb50000.vepu: probing finish
[   19.760802][    T1] mpp_vepu2 fdba0000.jpege-core: Adding to iommu group 5
[   19.768255][    T1] mpp_vepu2 fdba0000.jpege-core: probing start
[   19.774714][    T1] mpp_vepu2 fdba0000.jpege-core: attach ccu success
[   19.781661][    T1] mpp_vepu2 fdba0000.jpege-core: probing finish
[   19.788236][    T1] mpp_vepu2 fdba4000.jpege-core: Adding to iommu group 6
[   19.795697][    T1] mpp_vepu2 fdba4000.jpege-core: probing start
[   19.802169][    T1] mpp_vepu2 fdba4000.jpege-core: attach ccu success
[   19.809184][    T1] mpp_vepu2 fdba4000.jpege-core: probing finish
[   19.815779][    T1] mpp_vepu2 fdba8000.jpege-core: Adding to iommu group 7
[   19.823203][    T1] mpp_vepu2 fdba8000.jpege-core: probing start
[   19.829621][    T1] mpp_vepu2 fdba8000.jpege-core: attach ccu success
[   19.836579][    T1] mpp_vepu2 fdba8000.jpege-core: probing finish
[   19.843181][    T1] mpp_vepu2 fdbac000.jpege-core: Adding to iommu group 8
[   19.850672][    T1] mpp_vepu2 fdbac000.jpege-core: probing start
[   19.857113][    T1] mpp_vepu2 fdbac000.jpege-core: attach ccu success
[   19.862557][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   19.864172][    T1] mpp_vepu2 fdbac000.jpege-core: probing finish
[   19.877849][    T1] mpp-iep2 fdbb0000.iep: Adding to iommu group 9
[   19.884540][    T1] mpp-iep2 fdbb0000.iep: probe device
[   19.890207][    T1] mpp-iep2 fdbb0000.iep: allocate roi buffer failed
[   19.894784][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   19.897191][    T1] mpp-iep2 fdbb0000.iep: probing finish
[   19.910114][    T1] mpp_jpgdec fdb90000.jpegd: Adding to iommu group 4
[   19.917280][    T1] mpp_jpgdec fdb90000.jpegd: probe device
[   19.923384][    T1] mpp_jpgdec fdb90000.jpegd: probing finish
[   19.928117][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   19.929817][    T1] mpp_rkvdec2 fdc30000.rkvdec-ccu: rkvdec-ccu, probing start
[   19.944380][    T1] mpp_rkvdec2 fdc30000.rkvdec-ccu: ccu-mode: 1
[   19.950794][    T1] mpp_rkvdec2 fdc30000.rkvdec-ccu: probing finish
[   19.957551][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: Adding to iommu group 12
[   19.961450][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   19.965477][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: rkvdec-core, probing start
[   19.980287][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: shared_niu_a is not found!
[   19.988198][    T1] rkvdec2_init:1022: No niu aclk reset resource define
[   19.995328][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: shared_niu_h is not found!
[   19.998116][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.003205][    T1] rkvdec2_init:1025: No niu hclk reset resource define
[   20.017493][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: no regulator, devfreq is disabled
[   20.026112][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: core_mask=00010001
[   20.033356][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: attach ccu as core 0
[   20.034783][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.040863][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: sram_start 0x00000000ff001000
[   20.055914][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: rcb_iova 0x00000000fff00000
[   20.063954][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: sram_size 491520
[   20.070929][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: rcb_size 1048576
[   20.071449][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.077896][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: min_width 512
[   20.091661][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: rcb_info_count 20
[   20.098713][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [136, 24576]
[   20.105322][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [137, 49152]
[   20.111449][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.111914][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [141, 90112]
[   20.125510][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [140, 49152]
[   20.132128][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [139, 180224]
[   20.138833][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [133, 49152]
[   20.144782][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.145503][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [134, 8192]
[   20.159084][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [135, 4352]
[   20.165615][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [138, 13056]
[   20.172190][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: [142, 291584]
[   20.178116][  T152] rk-pcie fe170000.pcie: PCIe Linking... LTSSM is 0x3
[   20.178932][    T1] mpp_rkvdec2 fdc38100.rkvdec-core: probing finish
[   20.192829][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: Adding to iommu group 13
[   20.200730][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: rkvdec-core, probing start
[   20.208743][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: shared_niu_a is not found!
[   20.216614][    T1] rkvdec2_init:1022: No niu aclk reset resource define
[   20.223747][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: shared_niu_h is not found!
[   20.231717][    T1] rkvdec2_init:1025: No niu hclk reset resource define
[   20.238884][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: no regulator, devfreq is disabled
[   20.247474][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: core_mask=00020002
[   20.254616][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: attach ccu as core 1
[   20.262167][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: sram_start 0x00000000ff079000
[   20.270374][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: rcb_iova 0x00000000ffe00000
[   20.278398][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: sram_size 487424
[   20.285415][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: rcb_size 1048576
[   20.292407][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: min_width 512
[   20.299113][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: rcb_info_count 20
[   20.306200][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [136, 24576]
[   20.312818][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [137, 49152]
[   20.319471][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [141, 90112]
[   20.326108][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [140, 49152]
[   20.332735][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [139, 180224]
[   20.339440][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [133, 49152]
[   20.346076][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [134, 8192]
[   20.352582][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [135, 4352]
[   20.359087][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [138, 13056]
[   20.365715][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: [142, 291584]
[   20.372480][    T1] mpp_rkvdec2 fdc48100.rkvdec-core: probing finish
[   20.379449][    T1] mpp_rkvenc2 rkvenc-ccu: probing start
[   20.385203][    T1] mpp_rkvenc2 rkvenc-ccu: probing finish
[   20.391130][    T1] mpp_rkvenc2 fdbd0000.rkvenc-core: Adding to iommu group 10
[   20.399008][    T1] mpp_rkvenc2 fdbd0000.rkvenc-core: probing start
[   20.405846][    T1] mpp_rkvenc2 fdbd0000.rkvenc-core: dev_pm_opp_set_regulators: no regulator (venc) found: -19
[   20.416696][    T1] rkvenc_init:1814: failed to add venc devfreq
[   20.423156][    T1] mpp_rkvenc2 fdbd0000.rkvenc-core: attach ccu as core 0
[   20.430601][    T1] mpp_rkvenc2 fdbd0000.rkvenc-core: probing finish
[   20.437425][    T1] mpp_rkvenc2 fdbe0000.rkvenc-core: Adding to iommu group 11
[   20.445300][    T1] mpp_rkvenc2 fdbe0000.rkvenc-core: probing start
[   20.452070][    T1] mpp_rkvenc2 fdbe0000.rkvenc-core: dev_pm_opp_set_regulators: no regulator (venc) found: -19
[   20.462804][    T1] rkvenc_init:1814: failed to add venc devfreq
[   20.469248][    T1] mpp_rkvenc2 fdbe0000.rkvenc-core: attach ccu as core 1
[   20.476686][    T1] mpp_rkvenc2 fdbe0000.rkvenc-core: probing finish
[   20.483839][    T1] mpp_av1dec: Adding child /av1d@fdc70000
[   20.489877][    T1] mpp_av1dec: register device av1d-master
[   20.495874][    T1] mpp_av1dec av1d-master: av1_iommu_of_xlate,784
[   20.502514][    T1] av1_iommu_probe_device,737, consumer : av1d-master, supplier : fdca0000.iommu
[   20.511966][    T1] mpp_av1dec av1d-master: Adding to iommu group 18
[   20.519000][    T1] mpp_av1dec av1d-master: probing start
[   20.524958][    T1] mpp_av1dec av1d-master: probing finish
[   20.530925][    T1] mpp_service mpp-srv: probe success
[   20.544431][    T1] dma-pl330 fea10000.dma-controller: Loaded driver for PL330 DMAC-241330
[   20.552944][    T1] dma-pl330 fea10000.dma-controller:       DBUFF-128x8bytes Num_Chans-8 Num_Peri-32 Num_Events-16
[   20.563985][    T1] dma-pl330 fea30000.dma-controller: Loaded driver for PL330 DMAC-241330
[   20.572644][    T1] dma-pl330 fea30000.dma-controller:       DBUFF-128x8bytes Num_Chans-8 Num_Peri-32 Num_Events-16
[   20.583773][    T1] dma-pl330 fed10000.dma-controller: Loaded driver for PL330 DMAC-241330
[   20.592400][    T1] dma-pl330 fed10000.dma-controller:       DBUFF-128x8bytes Num_Chans-8 Num_Peri-32 Num_Events-16
[   20.603128][    T1] rockchip-pvtm fda40000.pvtm: pvtm@0 probed
[   20.609252][    T1] rockchip-pvtm fda50000.pvtm: pvtm@1 probed
[   20.615388][    T1] rockchip-pvtm fda60000.pvtm: pvtm@2 probed
[   20.621495][    T1] rockchip-pvtm fdaf0000.pvtm: pvtm@3 probed
[   20.627555][    T1] rockchip-pvtm fdb30000.pvtm: pvtm@4 probed
[   20.633922][    T1] rockchip-system-monitor rockchip-system-monitor: system monitor probe
[   20.643089][    T1] Serial: 8250/16550 driver, 10 ports, IRQ sharing disabled
[   20.650860][    T1] febc0000.serial: ttyS9 at MMIO 0xfebc0000 (irq = 93, base_baud = 1500000) is a 16550A
[   20.661257][  T176] random: crng init done
[   20.661871][    T1] rockchip-vop2 fdd90000.vop: Adding to iommu group 17
[   20.677954][    T1] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp0 assign plane mask: 0x5, primary plane phy id: 2
[   20.688746][    T1] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp1 assign plane mask: 0xa, primary plane phy id: 3
[   20.699582][    T1] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp2 assign plane mask: 0x140, primary plane phy id: 8
[   20.710563][    T1] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp3 assign plane mask: 0x280, primary plane phy id: 9
[   20.721683][    T1] rockchip-drm display-subsystem: failed to get hdmi0_phy_pll: -517
[   20.729955][    T1] [drm] failed to init overlay plane Cluster0-win1
[   20.736644][    T1] [drm] failed to init overlay plane Cluster1-win1
[   20.743321][    T1] [drm] failed to init overlay plane Cluster2-win1
[   20.750023][    T1] [drm] failed to init overlay plane Cluster3-win1
[   20.766157][    T1] rockchip-drm display-subsystem: bound fdd90000.vop (ops vop2_component_ops)
[   20.775234][    T1] dw-mipi-dsi2 fde20000.dsi: [drm:dw_mipi_dsi2_bind] *ERROR* Failed to find panel or bridge: -517
[   20.790224][    T1] panel-simple-dsi fde20000.dsi.0: supply power not found, using dummy regulator
[   20.803602][    T1] brd: module loaded
[   20.812218][    T1] loop: module loaded
[   20.816403][    T1] zram: Added device: zram0
[   20.821076][    T1] system_heap: orders[0] = 6
[   20.825681][    T1] system_heap: orders[1] = 4
[   20.830309][    T1] system_heap: orders[2] = 0
[   20.835928][    T1] ahci fe210000.sata: supply ahci not found, using dummy regulator
[   20.844082][    T1] ahci fe210000.sata: supply phy not found, using dummy regulator
[   20.852195][    T1] ahci fe210000.sata: supply target not found, using dummy regulator
[   20.860493][    T1] ahci fe210000.sata: forcing port_map 0x0 -> 0x1
[   20.867086][    T1] ahci fe210000.sata: AHCI 0001.0300 32 slots 1 ports 6 Gbps 0x1 impl platform mode
[   20.876639][    T1] ahci fe210000.sata: flags: ncq sntf pm led clo only pmp fbs pio slum part ccc apst
[   20.886482][    T1] ahci fe210000.sata: port 0 can do FBS, forcing FBSCP
[   20.894300][    T1] scsi host0: ahci
[   20.898187][    T1] ata1: SATA max UDMA/133 mmio [mem 0xfe210000-0xfe210fff] port 0x100 irq 76
[   20.907204][    T1] ahci fe230000.sata: supply ahci not found, using dummy regulator
[   20.915240][    T1] ahci fe230000.sata: supply phy not found, using dummy regulator
[   20.923240][    T1] ahci fe230000.sata: supply target not found, using dummy regulator
[   20.931567][    T1] ahci fe230000.sata: forcing port_map 0x0 -> 0x1
[   20.938046][    T1] ahci fe230000.sata: AHCI 0001.0300 32 slots 1 ports 6 Gbps 0x1 impl platform mode
[   20.947641][    T1] ahci fe230000.sata: flags: ncq sntf pm led clo only pmp fbs pio slum part ccc apst
[   20.957333][    T1] ahci fe230000.sata: port 0 can do FBS, forcing FBSCP
[   20.964916][    T1] scsi host1: ahci
[   20.968679][    T1] ata2: SATA max UDMA/133 mmio [mem 0xfe230000-0xfe230fff] port 0x100 irq 77
[   20.978737][    T1] rockchip-spi feb20000.spi: no high_speed pinctrl state
[   20.987069][    T1] rk806 spi2.0: chip id: RK806,ver:0x2, 0x1
[   20.993101][    T1] rk806 spi2.0: ON: 0x40 OFF:0x0
[   20.999392][    T1] vdd_gpu_s0: supplied by vcc5v0_sys
[   21.005714][    T1] vdd_cpu_lit_s0: supplied by vcc5v0_sys
[   21.011929][    T1] vdd_log_s0: supplied by vcc5v0_sys
[   21.017817][    T1] vdd_vdenc_s0: supplied by vcc5v0_sys
[   21.024001][    T1] vdd_ddr_s0: supplied by vcc5v0_sys
[   21.029751][    T1] vdd2_ddr_s3: supplied by vcc5v0_sys
[   21.035799][    T1] vdd_2v0_pldo_s3: supplied by vcc5v0_sys
[   21.041996][    T1] vcc_3v3_s3: supplied by vcc5v0_sys
[   21.047794][    T1] vddq_ddr_s0: supplied by vcc5v0_sys
[   21.053733][    T1] vcc_1v8_s3: supplied by vcc5v0_sys
[   21.059541][    T1] vdd_0v75_s3: supplied by vcc_1v1_nldo_s3
[   21.065887][    T1] vdd_ddr_pll_s0: supplied by vcc_1v1_nldo_s3
[   21.072423][    T1] avdd_0v75_s0: supplied by vcc_1v1_nldo_s3
[   21.078774][    T1] vdd_0v85_s0: supplied by vcc_1v1_nldo_s3
[   21.085158][    T1] vdd_0v75_s0: supplied by vcc_1v1_nldo_s3
[   21.091520][    T1] avcc_1v8_s0: supplied by vdd_2v0_pldo_s3
[   21.098004][    T1] vcc_1v8_s0: supplied by vdd_2v0_pldo_s3
[   21.104276][    T1] avdd_1v2_s0: supplied by vdd_2v0_pldo_s3
[   21.110627][    T1] vcc_3v3_s0: supplied by vcc5v0_sys
[   21.116258][    T1] vccio_sd_s0: supplied by vcc5v0_sys
[   21.122048][    T1] pldo6_s3: supplied by vcc5v0_sys
[   21.127699][    T1] rk806 spi2.0: no sleep-setting state
[   21.133260][    T1] rk806 spi2.0: no reset-setting pinctrl state
[   21.139569][    T1] rk806 spi2.0: no dvs-setting pinctrl state
[   21.146980][    T1] rockchip-spi feb20000.spi: probed, poll=0, rsd=0
[   21.154477][    T1] tun: Universal TUN/TAP device driver, 1.6
[   21.160653][    T1] CAN device driver interface
[   21.166905][    T1] rockchip-pinctrl pinctrl: pin gpio4-21 already requested by febc0000.serial; cannot claim for fe1b0000.ethernet
[   21.179279][    T1] rockchip-pinctrl pinctrl: pin-149 (fe1b0000.ethernet) status -22
[   21.187391][    T1] rockchip-pinctrl pinctrl: could not request pin 149 (gpio4-21) from group gmac0-miim  on device rockchip-pinctrl
[   21.199679][    T1] rk_gmac-dwmac fe1b0000.ethernet: Error applying setting, reverse things back
[   21.208787][    T1] rk_gmac-dwmac: probe of fe1b0000.ethernet failed with error -22
[   21.216754][    T1] PPP generic driver version 2.4.2
[   21.221138][  T181] ata1: SATA link down (SStatus 0 SControl 300)
[   21.221898][    T1] PPP BSD Compression module registered
[   21.233929][    T1] PPP Deflate Compression module registered
[   21.239968][    T1] PPP MPPE Compression module registered
[   21.245717][    T1] NET: Registered protocol family 24
[   21.251095][    T1] PPTP driver version 0.8.5
[   21.255786][    T1] usbcore: registered new interface driver catc
[   21.262199][    T1] usbcore: registered new interface driver kaweth
[   21.268629][    T1] pegasus: v0.9.3 (2013/04/25), Pegasus/Pegasus II USB Ethernet driver
[   21.277018][    T1] usbcore: registered new interface driver pegasus
[   21.283639][    T1] usbcore: registered new interface driver rtl8150
[   21.289151][  T183] ata2: SATA link down (SStatus 0 SControl 300)
[   21.290220][    T1] usbcore: registered new interface driver r8152
[   21.303125][    T1] hso: drivers/net/usb/hso.c: Option Wireless
[   21.309292][    T1] usbcore: registered new interface driver hso
[   21.315638][    T1] usbcore: registered new interface driver asix
[   21.321982][    T1] usbcore: registered new interface driver ax88179_178a
[   21.329164][    T1] usbcore: registered new interface driver cdc_ether
[   21.335983][    T1] usbcore: registered new interface driver cdc_eem
[   21.342525][    T1] usbcore: registered new interface driver dm9601
[   21.348958][    T1] usbcore: registered new interface driver smsc75xx
[   21.355686][    T1] usbcore: registered new interface driver smsc95xx
[   21.362348][    T1] usbcore: registered new interface driver gl620a
[   21.368864][    T1] usbcore: registered new interface driver net1080
[   21.375536][    T1] usbcore: registered new interface driver plusb
[   21.382069][    T1] usbcore: registered new interface driver rndis_host
[   21.389174][    T1] usbcore: registered new interface driver cdc_subset
[   21.396045][    T1] usbcore: registered new interface driver zaurus
[   21.402550][    T1] usbcore: registered new interface driver MOSCHIP usb-ethernet driver
[   21.410941][    T1] usbcore: registered new interface driver int51x1
[   21.417657][    T1] usbcore: registered new interface driver kalmia
[   21.424287][    T1] usbcore: registered new interface driver ipheth
[   21.430878][    T1] usbcore: registered new interface driver sierra_net
[   21.437742][    T1] usbcore: registered new interface driver cx82310_eth
[   21.444582][    T1] usbcore: registered new interface driver cdc_ncm
[   21.451253][    T1] usbcore: registered new interface driver qmi_wwan
[   21.457882][    T1] usbcore: registered new interface driver cdc_mbim
[   21.477426][    T1] ehci_hcd: USB 2.0 'Enhanced' Host Controller (EHCI) Driver
[   21.484919][    T1] ehci-pci: EHCI PCI platform driver
[   21.490334][    T1] ehci-platform: EHCI generic platform driver
[   21.498613][    T1] ehci-platform fc800000.usb: EHCI Host Controller
[   21.505331][    T1] ehci-platform fc800000.usb: new USB bus registered, assigned bus number 1
[   21.514128][    T1] ehci-platform fc800000.usb: irq 19, io mem 0xfc800000
[   21.531456][    T1] ehci-platform fc800000.usb: USB 2.0 started, EHCI 1.00
[   21.538633][    T1] usb usb1: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.10
[   21.547864][    T1] usb usb1: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   21.556089][    T1] usb usb1: Product: EHCI Host Controller
[   21.561983][    T1] usb usb1: Manufacturer: Linux 5.10.160+ ehci_hcd
[   21.568594][    T1] usb usb1: SerialNumber: fc800000.usb
[   21.574381][    T1] hub 1-0:1.0: USB hub found
[   21.579054][    T1] hub 1-0:1.0: 1 port detected
[   21.586211][    T1] ehci-platform fc880000.usb: EHCI Host Controller
[   21.592890][    T1] ehci-platform fc880000.usb: new USB bus registered, assigned bus number 2
[   21.601685][    T1] ehci-platform fc880000.usb: irq 21, io mem 0xfc880000
[   21.621455][    T1] ehci-platform fc880000.usb: USB 2.0 started, EHCI 1.00
[   21.628578][    T1] usb usb2: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.10
[   21.637974][    T1] usb usb2: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   21.646206][    T1] usb usb2: Product: EHCI Host Controller
[   21.652081][    T1] usb usb2: Manufacturer: Linux 5.10.160+ ehci_hcd
[   21.658726][    T1] usb usb2: SerialNumber: fc880000.usb
[   21.664429][    T1] hub 2-0:1.0: USB hub found
[   21.669110][    T1] hub 2-0:1.0: 1 port detected
[   21.674281][    T1] ohci_hcd: USB 1.1 'Open' Host Controller (OHCI) Driver
[   21.681465][    T1] ohci-platform: OHCI generic platform driver
[   21.687726][    T1] ohci-platform fc840000.usb: Generic Platform OHCI controller
[   21.696703][    T1] ohci-platform fc840000.usb: new USB bus registered, assigned bus number 3
[   21.705603][    T1] ohci-platform fc840000.usb: irq 20, io mem 0xfc840000
[   21.772183][    T1] usb usb3: New USB device found, idVendor=1d6b, idProduct=0001, bcdDevice= 5.10
[   21.781553][    T1] usb usb3: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   21.789820][    T1] usb usb3: Product: Generic Platform OHCI controller
[   21.796614][    T1] usb usb3: Manufacturer: Linux 5.10.160+ ohci_hcd
[   21.803259][    T1] usb usb3: SerialNumber: fc840000.usb
[   21.809065][    T1] hub 3-0:1.0: USB hub found
[   21.813749][    T1] hub 3-0:1.0: 1 port detected
[   21.818731][    T1] ohci-platform fc8c0000.usb: Generic Platform OHCI controller
[   21.826375][    T1] ohci-platform fc8c0000.usb: new USB bus registered, assigned bus number 4
[   21.835382][    T1] ohci-platform fc8c0000.usb: irq 22, io mem 0xfc8c0000
[   21.902182][    T1] usb usb4: New USB device found, idVendor=1d6b, idProduct=0001, bcdDevice= 5.10
[   21.911414][    T1] usb usb4: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   21.919568][    T1] usb usb4: Product: Generic Platform OHCI controller
[   21.926508][    T1] usb usb4: Manufacturer: Linux 5.10.160+ ohci_hcd
[   21.933145][    T1] usb usb4: SerialNumber: fc8c0000.usb
[   21.938881][    T1] hub 4-0:1.0: USB hub found
[   21.943512][    T1] hub 4-0:1.0: 1 port detected
[   21.948709][    T1] phy phy-fd5d4000.syscon:usb2-phy@4000.3: illegal mode
[   21.955734][    T1] xhci-hcd xhci-hcd.3.auto: xHCI Host Controller
[   21.962176][    T1] xhci-hcd xhci-hcd.3.auto: new USB bus registered, assigned bus number 5
[   21.970999][    T1] xhci-hcd xhci-hcd.3.auto: hcc params 0x0220fe64 hci version 0x110 quirks 0x0000200002010010
[   21.981361][    T1] xhci-hcd xhci-hcd.3.auto: irq 118, io mem 0xfc400000
[   21.988466][    T1] usb usb5: New USB device found, idVendor=1d6b, idProduct=0002, bcdDevice= 5.10
[   21.997687][    T1] usb usb5: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   22.005971][    T1] usb usb5: Product: xHCI Host Controller
[   22.011741][    T1] usb usb5: Manufacturer: Linux 5.10.160+ xhci-hcd
[   22.018483][    T1] usb usb5: SerialNumber: xhci-hcd.3.auto
[   22.024458][    T1] hub 5-0:1.0: USB hub found
[   22.029071][    T1] hub 5-0:1.0: 1 port detected
[   22.033948][    T1] xhci-hcd xhci-hcd.3.auto: xHCI Host Controller
[   22.040454][    T1] xhci-hcd xhci-hcd.3.auto: new USB bus registered, assigned bus number 6
[   22.049159][    T1] xhci-hcd xhci-hcd.3.auto: Host supports USB 3.0 SuperSpeed
[   22.056750][    T1] usb usb6: We don't know the algorithms for LPM for this host, disabling LPM.
[   22.065877][    T1] usb usb6: New USB device found, idVendor=1d6b, idProduct=0003, bcdDevice= 5.10
[   22.075184][    T1] usb usb6: New USB device strings: Mfr=3, Product=2, SerialNumber=1
[   22.083476][    T1] usb usb6: Product: xHCI Host Controller
[   22.089204][    T1] usb usb6: Manufacturer: Linux 5.10.160+ xhci-hcd
[   22.095800][    T1] usb usb6: SerialNumber: xhci-hcd.3.auto
[   22.101761][    T1] hub 6-0:1.0: USB hub found
[   22.106311][    T1] hub 6-0:1.0: 1 port detected
[   22.111246][    T1] usbcore: registered new interface driver cdc_acm
[   22.117842][    T1] cdc_acm: USB Abstract Control Model driver for USB modems and ISDN adapters
[   22.126902][    T1] usbcore: registered new interface driver cdc_wdm
[   22.133600][    T1] usbcore: registered new interface driver uas
[   22.139867][    T1] usbcore: registered new interface driver usb-storage
[   22.146906][    T1] usbcore: registered new interface driver usbserial_generic
[   22.154382][    T1] usbserial: USB Serial support registered for generic
[   22.161439][    T1] usbcore: registered new interface driver ch341
[   22.167883][    T1] usbserial: USB Serial support registered for ch341-uart
[   22.175217][    T1] usbcore: registered new interface driver option
[   22.181719][    T1] usbserial: USB Serial support registered for GSM modem (1-port)
[   22.189761][    T1] usbcore: registered new interface driver trancevibrator
[   22.198252][    T1] input: rk805 pwrkey as /devices/platform/feb20000.spi/spi_master/spi2/spi2.0/rk805-pwrkey.1.auto/input/input0
[   22.210327][    T1] i2c /dev entries driver
[   22.217911][    T1] vdd_cpu_big0_s0: supplied by vcc5v0_sys
[   22.230774][    T1] vdd_cpu_big1_s0: supplied by vcc5v0_sys
[   22.241197][    T1] reset gpio : 113
[   22.348122][    T1] rk3x-i2c fead0000.i2c: timeout, ipd: 0x00, state: 3
[   22.354956][    T1] synaptics_dsx_i2c 5-0020: synaptics_rmi4_i2c_set_page: I2C retry 1
[   22.388119][    T1] synaptics_dsx_i2c 5-0020: synaptics_rmi4_set_input_dev: Failed to query device
[   22.397412][    T1] synaptics_dsx synaptics_dsx.0: synaptics_rmi4_probe: Failed to set up input device
[   22.407149][    T1] synaptics_dsx: probe of synaptics_dsx.0 failed with error -5
[   22.418626][    T1] rtc-hym8563 6-0051: rtc information is invalid
[   22.431835][    T1] rtc-hym8563 6-0051: registered as rtc0
[   22.438572][    T1] rtc-hym8563 6-0051: setting system clock to 2021-01-01T12:00:00 UTC (1609502400)
[   22.450668][    T1] rkcifhw fdce0000.rkcif: Adding to iommu group 16
[   22.457499][    T1] rkcifhw fdce0000.rkcif: No reserved memory region assign to CIF
[   22.466517][    T1] rkisp_hw fdcb0000.rkisp: Adding to iommu group 14
[   22.473278][    T1] rkisp_hw fdcb0000.rkisp: is_thunderboot: 0
[   22.479363][    T1] rkisp_hw fdcb0000.rkisp: max input:0x0@0fps
[   22.485672][    T1] rkisp_hw fdcb0000.rkisp: Missing rockchip,grf property
[   22.492784][    T1] rkisp_hw fdcb0000.rkisp: no find phandle sram
[   22.499219][    T1] rkisp_hw fdcc0000.rkisp: Adding to iommu group 15
[   22.506016][    T1] rkisp_hw fdcc0000.rkisp: is_thunderboot: 0
[   22.512057][    T1] rkisp_hw fdcc0000.rkisp: max input:0x0@0fps
[   22.518253][    T1] rkisp_hw fdcc0000.rkisp: Missing rockchip,grf property
[   22.525468][    T1] rkisp_hw fdcc0000.rkisp: no find phandle sram
[   22.532497][    T1] usbcore: registered new interface driver uvcvideo
[   22.539275][    T1] USB Video Class driver (1.1.1)
[   22.544670][    T1] __power_supply_register: Expected proper parent device for 'test_ac'
[   22.553234][    T1] __power_supply_register: Expected proper parent device for 'test_battery'
[   22.562163][    T1] thermal thermal_zone7: power_allocator: sustainable_power will be estimated
[   22.571193][    T1] __power_supply_register: Expected proper parent device for 'test_usb'
[   22.580062][    T1] Bluetooth: HCI UART driver ver 2.3
[   22.585404][    T1] Bluetooth: HCI UART protocol H4 registered
[   22.592196][    T1] cpu cpu0: bin=0
[   22.596098][    T1] cpu cpu0: leakage=11
[   22.601591][    T1] cpu cpu0: pvtm=1476
[   22.605836][    T1] cpu cpu0: pvtm-volt-sel=3
[   22.612296][    T1] cpu cpu4: bin=0
[   22.616105][    T1] cpu cpu4: leakage=9
[   22.618137][  T152] rk-pcie fe170000.pcie: PCIe Link Fail
[   22.625844][  T152] rk-pcie fe170000.pcie: failed to initialize host
[   22.626498][    T1] cpu cpu4: pvtm=1691
[   22.640769][    T1] cpu cpu4: pvtm-volt-sel=4
[   22.647913][    T1] cpu cpu6: bin=0
[   22.651793][    T1] cpu cpu6: leakage=9
[   22.662220][    T1] cpu cpu6: pvtm=1697
[   22.670209][    T1] cpu cpu6: pvtm-volt-sel=4
[   22.676098][    T1] cpu cpu0: avs=0
[   22.680281][    T1] cpu cpu4: avs=0
[   22.684479][    T1] cpu cpu6: avs=0
[   22.688279][    T1] cpu cpu0: EM: created perf domain
[   22.693419][    T1] cpu cpu0: l=10000 h=85000 hyst=5000 l_limit=0 h_limit=1608000000 h_table=0
[   22.703006][    T1] cpu cpu4: EM: created perf domain
[   22.708531][    T1] cpu cpu4: l=10000 h=85000 hyst=5000 l_limit=0 h_limit=2208000000 h_table=0
[   22.726525][    T1] cpu cpu6: EM: created perf domain
[   22.732466][    T1] cpu cpu6: l=10000 h=85000 hyst=5000 l_limit=0 h_limit=2208000000 h_table=0
[   22.756619][    T1] sdhci: Secure Digital Host Controller Interface driver
[   22.763860][    T1] sdhci: Copyright(c) Pierre Ossman
[   22.769127][    T1] Synopsys Designware Multimedia Card Interface Driver
[   22.776273][    T1] sdhci-pltfm: SDHCI platform and OF driver helper
[   22.776704][    T7] dwmmc_rockchip fe2d0000.mmc: IDMAC supports 32-bit address mode.
[   22.776864][    T9] dwmmc_rockchip fe2c0000.mmc: IDMAC supports 32-bit address mode.
[   22.776887][    T9] dwmmc_rockchip fe2c0000.mmc: Using internal DMA controller.
[   22.776893][    T9] dwmmc_rockchip fe2c0000.mmc: Version ID is 270a
[   22.776916][    T9] dwmmc_rockchip fe2c0000.mmc: DW MMC controller at irq 78,32 bit host data width,256 deep fifo
[   22.783239][    T1] arm-scmi firmware:scmi: Failed. SCMI protocol 17 not active.
[   22.791374][    T7] dwmmc_rockchip fe2d0000.mmc: Using internal DMA controller.
[   22.799620][    T1] SMCCC: SOC_ID: ARCH_FEATURES(ARCH_SOC_ID) returned error: fffffffffffffffd
[   22.807546][    T7] dwmmc_rockchip fe2d0000.mmc: Version ID is 270a
[   22.814751][    T1] cryptodev: driver 1.12 loaded.
[   22.823225][    T9] mmc_host mmc1: Bus speed (slot 0) = 400000Hz (slot req 400000Hz, actual 400000HZ div = 0)
[   22.825325][    T7] dwmmc_rockchip fe2d0000.mmc: DW MMC controller at irq 79,32 bit host data width,256 deep fifo
[   22.833245][    T1] hid: raw HID events driver (C) Jiri Kosina
[   22.841753][  T185] mmc0: SDHCI controller on fe2e0000.mmc [fe2e0000.mmc] using ADMA
[   22.848612][    T7] dwmmc_rockchip fe2d0000.mmc: allocated mmc-pwrseq
[   22.848614][    T7] mmc_host mmc2: card is non-removable.
[   22.850062][    T1] usbcore: registered new interface driver usbhid
[   22.884596][   T61] mmc_host mmc1: Bus speed (slot 0) = 148500000Hz (slot req 150000000Hz, actual 148500000HZ div = 0)
[   22.888559][    T1] usbhid: USB HID core driver
[   22.888747][    T1] ashmem: initialized
[   22.905783][  T196] mmc0: Host Software Queue enabled
[   22.909354][    T1] zrhung hung_wp_screen_init start
[   22.915983][  T196] mmc0: new HS400 Enhanced strobe MMC card at address 0001
[   22.927176][    T1] zrhung hung_wp_screen_init done
[   22.932357][  T196] mmcblk0: mmc0:0001 AT2S9C 58.2 GiB
[   22.937324][    T1] optee: probing for conduit method.
[   22.941370][  T196] mmcblk0boot0: mmc0:0001 AT2S9C partition 1 4.00 MiB
[   22.946457][    T1] optee: revision 3.13 (b5340fd6)
[   22.954186][  T196] mmcblk0boot1: mmc0:0001 AT2S9C partition 2 4.00 MiB
[   22.959420][    T1] optee: dynamic shared memory is enabled
[   22.965099][  T196] mmcblk0rpmb: mmc0:0001 AT2S9C partition 3 4.00 MiB, chardev (234:0)
[   22.970153][    T1] optee: initialized driver
[   22.980326][  T196]  mmcblk0: p1 p2 p3 p4 p5 p6 p7 p8 p9 p10 p11
[   22.982477][    T1] access_token_id: access_tokenid init success
[   23.020531][    T1] usbcore: registered new interface driver snd-usb-audio
[   23.029924][    T1] netem: version 1.3
[   23.033805][    T1] u32 classifier
[   23.037345][    T1]     input device check on
[   23.039104][   T61] dwmmc_rockchip fe2c0000.mmc: Successfully tuned phase to 3
[   23.041855][    T1]     Actions configured
[   23.042164][    T1] xt_time: kernel timezone is -0000
[   23.049664][   T61] mmc1: new ultra high speed SDR104 SDXC card at address 5048
[   23.053901][    T1] gre: GRE over IPv4 demultiplexor driver
[   23.059742][   T61] mmcblk1: mmc1:5048 SD64G 58.0 GiB
[   23.064835][    T7] mmc_host mmc2: Bus speed (slot 0) = 400000Hz (slot req 400000Hz, actual 400000HZ div = 0)
[   23.066833][    T1] IPv4 over IPsec tunneling driver
[   23.067014][    T1] Initializing XFRM netlink socket
[   23.074892][   T61]  mmcblk1: p2
[   23.078236][    T1] IPsec XFRM device driver
[   23.078308][    T1] NET: Registered protocol family 10
[   23.112679][    T1] Segment Routing with IPv6
[   23.117281][    T1] mip6: Mobile IPv6
[   23.121212][    T1] sit: IPv6, IPv4 and MPLS over IPv4 tunneling driver
[   23.128239][    T1] NET: Registered protocol family 17
[   23.133542][    T1] NET: Registered protocol family 15
[   23.138780][    T1] Bridge firewalling registered
[   23.143627][    T1] can: controller area network core
[   23.148850][    T1] NET: Registered protocol family 29
[   23.154143][    T1] can: raw protocol
[   23.157926][    T1] can: broadcast manager protocol
[   23.162995][    T1] can: netlink gateway - max_hops=1
[   23.168506][    T1] Bluetooth: RFCOMM TTY layer initialized
[   23.174280][    T1] Bluetooth: RFCOMM socket layer initialized
[   23.180363][    T1] Bluetooth: RFCOMM ver 1.11
[   23.184939][    T1] Bluetooth: BNEP (Ethernet Emulation) ver 1.3
[   23.191088][    T1] Bluetooth: BNEP filters: protocol multicast
[   23.197263][    T1] Bluetooth: BNEP socket layer initialized
[   23.203142][    T1] Bluetooth: HIDP (Human Interface Emulation) ver 1.2
[   23.209967][    T1] Bluetooth: HIDP socket layer initialized
[   23.216020][    T1] l2tp_core: L2TP core driver, V2.0
[   23.221243][    T1] l2tp_ppp: PPPoL2TP kernel driver, V2.0
[   23.226846][    T1] [BT_RFKILL]: Enter rfkill_rk_init
[   23.232084][    T1] [WLAN_RFKILL]: Enter rfkill_wlan_init
[   23.237797][    T1] Key type dns_resolver registered
[   23.243345][    T1] registered taskstats version 1
[   23.248362][    T1] Loading compiled-in X.509 certificates
[   23.251625][  T216] vendor storage:20190527 ret = 0
[   23.254038][    T1] Key type .fscrypt registered
[   23.264025][    T1] Key type fscrypt-provisioning registered
[   23.270000][    T1] pstore: Using crash dump compression: deflate
[   23.276445][    T1] rga3_core0 fdb60000.rga: Adding to iommu group 2
[   23.283131][    T1] rga: rga3_core0, irq = 34, match scheduler
[   23.289412][    T1] rga: rga3_core0 hardware loaded successfully, hw_version:3.0.76831.
[   23.297702][    T1] rga: rga3_core0 probe successfully
[   23.303125][    T1] rga3_core1 fdb70000.rga: Adding to iommu group 3
[   23.309808][    T1] rga: rga3_core1, irq = 35, match scheduler
[   23.316139][    T1] rga: rga3_core1 hardware loaded successfully, hw_version:3.0.76831.
[   23.324428][    T1] rga: rga3_core1 probe successfully
[   23.329844][    T1] rga: rga2, irq = 36, match scheduler
[   23.335631][    T1] rga: rga2 hardware loaded successfully, hw_version:3.2.63318.
[   23.343463][    T1] rga: rga2 probe successfully
[   23.348249][    T1] rga_iommu: IOMMU binding successfully, default mapping core[0x1]
[   23.356300][    T1] rga: Module initialized. v1.2.26
[   23.361453][    T1]
[   23.363716][    T1] ********************************************************************
[   23.372048][    T1] **     NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE           **
[   23.380440][    T1] **                                                                **
[   23.388781][    T1] **  WRITEABLE clk DebugFS SUPPORT HAS BEEN ENABLED IN THIS KERNEL **
[   23.397138][    T1] **                                                                **
[   23.405435][    T1] ** This means that this kernel is built to expose clk operations  **
[   23.413846][    T1] ** such as parent or rate setting, enabling, disabling, etc.      **
[   23.422264][    T1] ** to userspace, which may compromise security on your system.    **
[   23.430595][    T1] **                                                                **
[   23.438892][    T1] ** If you see this message and you are not debugging the          **
[   23.447345][    T1] ** kernel, report this immediately to your vendor!                **
[   23.455659][    T1] **                                                                **
[   23.463956][    T1] **     NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE           **
[   23.472296][    T1] ********************************************************************
[   23.492262][    T7] combophy_avdd0v85: supplied by vdd_0v85_s0
[   23.492599][  T185] mali fb000000.gpu: Kernel DDK version g17p0-01eac0
[   23.498964][    T7] combophy_avdd1v8: supplied by avcc_1v8_s0
[   23.506101][  T185] mali fb000000.gpu: bin=0
[   23.516200][    T7] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp0 assign plane mask: 0x5, primary plane phy id: 2
[   23.516504][  T185] mali fb000000.gpu: leakage=16
[   23.527579][    T7] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp1 assign plane mask: 0xa, primary plane phy id: 3
[   23.532644][  T185] debugfs: Directory 'fb000000.gpu-mali' with parent 'vdd_gpu_s0' already present!
[   23.543891][    T7] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp2 assign plane mask: 0x140, primary plane phy id: 8
[   23.565136][    T7] rockchip-vop2 fdd90000.vop: [drm:vop2_bind] vp3 assign plane mask: 0x280, primary plane phy id: 9
[   23.566561][  T185] mali fb000000.gpu: pvtm=861
[   23.576050][    T7] rockchip-drm display-subsystem: failed to get hdmi0_phy_pll: -517
[   23.576153][    T7] [drm] failed to init overlay plane Cluster0-win1
[   23.585694][  T185] mali fb000000.gpu: pvtm-volt-sel=3
[   23.586579][  T151] dwmmc_rockchip fe2d0000.mmc: Busy; trying anyway
[   23.588944][    T7] [drm] failed to init overlay plane Cluster1-win1
[   23.595868][  T185] mali fb000000.gpu: avs=0
[   23.600943][    T7] [drm] failed to init overlay plane Cluster2-win1
[   23.608383][  T185] W : [File] : drivers/gpu/arm/bifrost/platform/rk/mali_kbase_config_rk.c; [Line] : 143; [Func] : kbase_platform_rk_init(); power-off-delay-ms not available.
[   23.614229][    T7] [drm] failed to init overlay plane Cluster3-win1
[   23.625260][  T185] mali fb000000.gpu: GPU hardware issue table may need updating:
[   23.625260][  T185] r0p0 status 5 is unknown; treating as r0p0 status 0
[   23.630237][    T7] rockchip-drm display-subsystem: bound fdd90000.vop (ops vop2_component_ops)
[   23.640976][  T185] mali fb000000.gpu: GPU identified as 0x7 arch 10.8.6 r0p0 status 0
[   23.647637][    T7] rockchip-drm display-subsystem: bound fde20000.dsi (ops dw_mipi_dsi2_ops)
[   23.662615][  T185] mali fb000000.gpu: No priority control manager is configured
[   23.672293][    T7] [drm:rockchip_drm_show_logo] *ERROR* Reserved logo memory should be aligned as:0x1000, cureent is:start[0x00000000edf00000] size[0x0000000000083550]
[   23.679942][  T185] mali fb000000.gpu: No memory group manager is configured
[   23.688645][    T7] rockchip-drm display-subsystem: route-dsi0: failed to get logo,offset
[   23.696182][  T185] mali fb000000.gpu: Protected memory allocator not available
[   23.711819][    T7] rockchip-drm display-subsystem: can't not find any logo display
[   23.719547][  T185] mali fb000000.gpu: Capping CSF_FIRMWARE_TIMEOUT to CSF_FIRMWARE_PING_TIMEOUT
[   23.727640][    T7] rockchip-drm display-subsystem: failed to show kernel logo
[   23.735406][  T185] mali fb000000.gpu: l=10000 h=85000 hyst=5000 l_limit=0 h_limit=800000000 h_table=0
[   23.746113][  T194] rockchip-vop2 fdd90000.vop: [drm:vop2_crtc_atomic_enable] Update mode to 1080x2160p66, type: 16(if:20) for vp3 dclk: 157287000
[   23.752726][  T185] mali fb000000.gpu: Probed as mali0
[   23.788419][    T7] rockchip-drm display-subsystem: [drm] fb0: rockchipdrmfb frame buffer device
[   23.797842][    T7] [drm] Initialized rockchip 3.0.0 20140818 for display-subsystem on minor 0
[   23.807087][    T7] input: adc-keys as /devices/platform/adc-keys/input/input2
[   23.809791][  T194] rockchip-vop2 fdd90000.vop: [drm:vop2_wait_power_domain_off] *ERROR* wait pd7 off timeout power_ctrl: 0x7f
[   23.826435][    T1] [I/osal_cdev] register hdf class success
[   23.826447][  T194] rockchip-vop2 fdd90000.vop: [drm:vop2_crtc_atomic_enable] dclk_out3 div: 2 dclk_core3 div: 2
[   23.832502][    T1] [I/osal_cdev] add cdev dev_mgr success
[   23.832502][    T1]
[   23.842923][  T194] rockchip-vop2 fdd90000.vop: [drm:vop2_crtc_atomic_enable] set dclk_vop3 to 157287000, get 157286399
[   23.851058][    T1] [I/osal_cdev] add cdev devsvc_mgr success
[   23.851058][    T1]
[   23.870494][    T1] [I/devmgr_service] start svcmgr result 0
[   23.876455][    T1] [I/hcs_blob_if] CheckHcsBlobLength: the blobLength: 39600, byteAlign: 1
[   23.885361][    T1] [I/device_node] launch devnode
[   23.890497][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:0, count:32)
[   23.899779][    T1] [I/gpio_manager] GpioManagerAdd: start:0 count:32 added success!
[   23.907844][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:0, count:32) succeed!
[   23.918342][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:32, count:32)
[   23.927740][    T1] [I/gpio_manager] GpioManagerAdd: start:32 count:32 added success!
[   23.935969][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:32, count:32) succeed!
[   23.946562][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:64, count:32)
[   23.956015][    T1] [I/gpio_manager] GpioManagerAdd: start:64 count:32 added success!
[   23.964140][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:64, count:32) succeed!
[   23.974784][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:96, count:32)
[   23.984191][    T1] [I/gpio_manager] GpioManagerAdd: start:96 count:32 added success!
[   23.992359][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:96, count:32) succeed!
[   24.002943][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:128, count:32)
[   24.012400][    T1] [I/gpio_manager] GpioManagerAdd: start:128 count:32 added success!
[   24.020629][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:128, count:32) succeed!
[   24.031299][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: find gpio chip(start:509, count:3)
[   24.040719][    T1] [I/gpio_manager] GpioManagerAdd: start:509 count:3 added success!
[   24.048930][    T1] [I/linux_gpio_adapter] LinuxGpioMatchProbe: add gpio controller(start:509, count:3) succeed!
[   24.059592][    T1] [I/linux_gpio_adapter] LinuxGpioInit: dev service: init done!
[   24.067738][    T1] [I/device_node] launch devnode HDF_PLATFORM_GPIO_MANAGER
[   24.075578][    T1] [I/gpio_service] GpioServiceBind: enter!
[   24.081705][    T1] [I/gpio_service] GpioServiceBind: success!
[   24.086583][  T151] mmc_host mmc2: Timeout sending command (cmd 0x202000 arg 0x0 status 0x80202000)
[   24.087901][    T1] [I/osal_cdev] add cdev HDF_PLATFORM_GPIO_MANAGER success
[   24.087901][    T1]
[   24.106783][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_PLATFORM_EMMC
[   24.116876][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_MMC_0, ret = -207
[   24.125937][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_PLATFORM_WATCHDOG
[   24.136410][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_WATCHDOG_0, ret = -207
[   24.146044][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_PLATFORM_RTC
[   24.156118][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_RTC, ret = -207
[   24.165141][    T1] [I/device_node] launch devnode HDF_PLATFORM_UART_0
[   24.172044][    T1] [I/hdf_uart_adapter] HdfUartBind: entry!
[   24.178080][    T1] [I/hdf_uart_adapter] HdfUartInit: entry!
[   24.183969][    T1] [E/hcs_tree_if] HcsGetUint32 failed, the attr of num is NULL, or the value is NULL, the value is default value
[   24.196192][    T1] [E/hdf_uart_adapter] HdfUartInit: read num fail!
[   24.202852][    T1] [I/device_node] release devnode HDF_PLATFORM_UART_0
[   24.204877][  T194] dw-mipi-dsi2 fde20000.dsi: [drm:dw_mipi_dsi2_encoder_enable] final DSI-Link bandwidth: 1200000 x 4 Kbps
[   24.209755][    T1] [I/hdf_uart_adapter] HdfUartRelease: entry!
[   24.209757][    T1] [E/devmgr_service] devmgr detach device 1000401 not found
[   24.209758][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_UART_0, ret = -204
[   24.244623][    T1] [I/device_node] launch devnode HDF_PLATFORM_I2C_MANAGER
[   24.251958][    T1] [I/i2c_core] I2cManagerBind: enter!
[   24.257568][    T1] [I/osal_cdev] add cdev HDF_PLATFORM_I2C_MANAGER success
[   24.257568][    T1]
[   24.267076][    T1] [I/device_node] launch devnode
[   24.272176][    T1] [I/i2c_linux_adapter] LinuxI2cInit: enter!
[   24.278334][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: enter!
[   24.284483][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: i2c adapter 0 add success!
[   24.292574][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: enter!
[   24.298827][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: i2c adapter 5 add success!
[   24.306813][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: enter!
[   24.313057][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: i2c adapter 6 add success!
[   24.315009][  T151] mmc_host mmc2: Bus speed (slot 0) = 300000Hz (slot req 300000Hz, actual 300000HZ div = 0)
[   24.321174][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: enter!
[   24.321176][    T1] [I/i2c_linux_adapter] LinuxI2cProbe: i2c adapter 7 add success!
[   24.321177][    T1] [I/i2c_linux_adapter] LinuxI2cInit: done!
[   24.321185][    T1] [I/device_node] launch devnode HDF_PLATFORM_SPI_1
[   24.321186][    T1] [I/HDF_SPI_LINUX_ADAPTER] HdfSpiDeviceBind: entry!
[   24.321388][    T1] [I/HDF_SPI_LINUX_ADAPTER] HdfSpiDeviceInit: entry!
[   24.372960][    T1] [I/device_node] launch devnode HDF_PLATFORM_SPI_0
[   24.379697][    T1] [I/HDF_SPI_LINUX_ADAPTER] HdfSpiDeviceBind: entry!
[   24.386495][    T1] [I/HDF_SPI_LINUX_ADAPTER] HdfSpiDeviceInit: entry!
[   24.393398][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_PLATFORM_ADC_MANAGER
[   24.404185][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_ADC_MANAGER, ret = -207
[   24.413913][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver linux_adc_adapter
[   24.424014][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   24.431514][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_PLATFORM_SDIO
[   24.441640][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_PLATFORM_MMC_2, ret = -207
[   24.450836][    T1] [I/device_node] launch devnode HDF_PLATFORM_PWM_1
[   24.457608][    T1] [I/pwm_adapter] HdfPwmInit: entry!
[   24.463107][    T1] [I/osal_cdev] add cdev HDF_PLATFORM_PWM_1 success
[   24.463107][    T1]
[   24.472105][    T1] [I/device_node] launch devnode HDF_PLATFORM_PWM_0
[   24.478903][    T1] [I/pwm_adapter] HdfPwmInit: entry!
[   24.484408][    T1] [I/osal_cdev] add cdev HDF_PLATFORM_PWM_0 success
[   24.484408][    T1]
[   24.493419][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_MIPI_TX
[   24.503042][    T1] [E/devhost_service_clnt] failed to AddDevice HDF_MIPI_TX, ret = -207
[   24.511592][    T1] [I/device_node] launch devnode hdf_kevent
[   24.517551][    T1] [I/kevent] HdfKeventDriverInit:register pm notifier success
[   24.525278][    T1] [I/kevent] HdfKeventDriverInit:register fb notifier success
[   24.533019][    T1] [I/osal_cdev] add cdev hdf_kevent success
[   24.533019][    T1]
[   24.541298][    T1] [I/device_node] launch devnode hdf_light
[   24.547548][    T1] [I/osal_cdev] add cdev hdf_light success
[   24.547548][    T1]
[   24.555850][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_VIBRATOR
[   24.565596][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_VIBRATOR not found
[   24.574413][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_misc_vibrator, ret = -207
[   24.583447][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_LINEAR_VIBRATOR
[   24.593694][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_LINEAR_VIBRATOR not found
[   24.603076][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_misc_linear_vibrator, ret = -207
[   24.612731][    T1] [I/device_node] launch devnode hdf_usb_pnp_notify_service
[   24.620248][    T1] [I/USB_PNP_NOTIFY] UsbPnpNotifyBind: Enter!
[   24.626464][    T1] [I/USB_PNP_NOTIFY] UsbPnpNotifyInit: Enter!
[   24.633063][    T1] [I/osal_cdev] add cdev hdf_usb_pnp_notify_service success
[   24.633063][    T1]
[   24.642864][    T1] [I/device_node] launch devnode hdf_sensor_manager_ap
[   24.649871][    T1] [I/khdf_sensor_common_driver] InitSensorDevManager: init sensor manager successfully
[   24.659918][    T1] [I/osal_cdev] add cdev hdf_sensor_manager_ap success
[   24.659918][    T1]
[   24.669198][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_SENSOR_PROXIMITY
[   24.679593][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_SENSOR_PROXIMITY not found
[   24.689069][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_sensor_proximity, ret = -207
[   24.698406][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_SENSOR_ALS
[   24.708333][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_SENSOR_ALS not found
[   24.717245][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_sensor_als, ret = -207
[   24.725994][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_SENSOR_ACCEL
[   24.735973][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_SENSOR_ACCEL not found
[   24.745172][    T1] [E/devhost_service_clnt] failed to AddDevice sensor_accel, ret = -207
[   24.753740][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_WIFI
[   24.763103][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_WIFI not found
[   24.771461][    T1] [E/devhost_service_clnt] failed to AddDevice hdfwifi, ret = -207
[   24.779627][    T1] [I/device_node] launch devnode hdf_input_host
[   24.786061][    T1] [I/HDF_LOG_TAG] HdfInputManagerInit: enter
[   24.792218][    T1] [I/HDF_LOG_TAG] HdfInputManagerInit: exit succ
[   24.798724][    T1] [I/osal_cdev] add cdev hdf_input_host success
[   24.798724][    T1]
[   24.807434][    T1] [I/device_node] launch devnode
[   24.812586][    T1] [I/HDF_LOG_TAG] LoadCachedHid: exit
[   24.818143][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_BL
[   24.827220][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_BL not found
[   24.835474][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_bl, ret = -207
[   24.843564][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver PWM_BL
[   24.852684][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver PWM_BL not found
[   24.855678][  T151] dwmmc_rockchip fe2d0000.mmc: Busy; trying anyway
[   24.860836][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   24.874881][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver LCD_ILI9881_ST_5P5
[   24.885076][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver LCD_ILI9881_ST_5P5 not found
[   24.894353][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   24.901827][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver LCD_ICN9700
[   24.911381][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver LCD_ICN9700 not found
[   24.920077][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   24.927629][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HI351XX_DISP
[   24.937314][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HI351XX_DISP not found
[   24.946009][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   24.953510][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_DISP
[   24.962821][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_DISP not found
[   24.971144][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_disp, ret = -207
[   24.979320][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_DRMPANEL
[   24.989004][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_DRMPANEL not found
[   24.997743][    T1] [E/devhost_service_clnt] failed to AddDevice , ret = -207
[   25.005244][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver DMA_RK3588
[   25.014737][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver DMA_RK3588 not found
[   25.023363][    T1] [E/devhost_service_clnt] failed to AddDevice hdmi_dma_service_0, ret = -207
[   25.032389][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver DMA_RK3588
[   25.041804][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver DMA_RK3588 not found
[   25.050422][    T1] [E/devhost_service_clnt] failed to AddDevice dma_service_0, ret = -207
[   25.059124][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver DSP_RK3588
[   25.068661][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver DSP_RK3588 not found
[   25.077190][    T1] [E/devhost_service_clnt] failed to AddDevice dsp_service_0, ret = -207
[   25.085895][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver AUDIO_HDMI_CODEC
[   25.095882][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver AUDIO_HDMI_CODEC not found
[   25.104977][    T1] [E/devhost_service_clnt] failed to AddDevice codec_service_1, ret = -207
[   25.113829][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver CODEC_ES8323
[   25.123478][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver CODEC_ES8323 not found
[   25.132201][    T1] [E/devhost_service_clnt] failed to AddDevice codec_service_0, ret = -207
[   25.141035][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver DAI_RK3588
[   25.150537][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver DAI_RK3588 not found
[   25.159068][    T1] [E/devhost_service_clnt] failed to AddDevice hdmi_dai_service, ret = -207
[   25.167981][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver DAI_RK3588
[   25.177431][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver DAI_RK3588 not found
[   25.185927][    T1] [E/devhost_service_clnt] failed to AddDevice dai_service, ret = -207
[   25.194398][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_AUDIO
[   25.203814][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_AUDIO not found
[   25.212302][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_audio_codec_primary_dev0, ret = -207
[   25.222289][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_AUDIO_CONTROL
[   25.232467][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_AUDIO_CONTROL not found
[   25.241700][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_audio_control, ret = -207
[   25.250613][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_AUDIO_STREAM
[   25.260609][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_AUDIO_STREAM not found
[   25.269678][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_audio_capture, ret = -207
[   25.278644][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver HDF_AUDIO_STREAM
[   25.288613][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver HDF_AUDIO_STREAM not found
[   25.297768][    T1] [E/devhost_service_clnt] failed to AddDevice hdf_audio_render, ret = -207
[   25.306629][    T1] [I/HDF_LOG_TAG] HdfDriverManagerGetDriver:try to dynamic load driver AUDIO_ANALOG_HEADSET
[   25.317067][    T1] [E/HDF_LOG_TAG] HdfDriverManagerGetDriver:driver AUDIO_ANALOG_HEADSET not found
[   25.326578][    T1] [E/devhost_service_clnt] failed to AddDevice analog_headset_service, ret = -207
[   25.335998][    T1] [I/hdf_power_manager] HdfPmTaskQueueInit HdfTaskQueueCreate success
[   25.344616][    T1] cfg80211: Loading compiled-in X.509 certificates for regulatory database
[   25.354380][    T1] cfg80211: Loaded X.509 cert 'sforshee: 00b28ddf47aef9cea7'
[   25.361887][  T188] platform regulatory.0: Direct firmware load for regulatory.db failed with error -2
[
